ESP32c3 WiFi Tutorials

Wi-Fi Sniffer on ESP32c3 - Code Documentation Overview:

Full Source Code Available Here

This program demonstrates a Wi-Fi sniffer running on an ESP32, capable of detecting Wi-Fi networks (beacon frames) and data frames in promiscuous mode. The program cycles through Wi-Fi channels, processes packets, and extracts SSID and MAC address details, filtering out duplicates. The sniffer provides real-time Wi-Fi network activity and maintains a list of previously seen MAC addresses to avoid redundant reporting. Key Features:

Wi-Fi Packet Sniffing: Captures both management (beacon frames) and data frames. Channel Hopping: Cycles through Wi-Fi channels 1 to 13. Duplicate Filtering: Ensures that the same network or device is not reported multiple times. Real-Time Reporting: Prints SSID, MAC address, and RSSI (signal strength) for each detected network.

Code Breakdown:

1. Imports and Setup:

    #include <string.h>
    #include "freertos/FreeRTOS.h"
    #include "freertos/task.h"
    #include "esp_wifi.h"
    #include "esp_log.h"
    #include "nvs_flash.h"
    #include "esp_event.h"

These headers include necessary libraries for FreeRTOS tasks, Wi-Fi functions, logging, and flash memory handling.

2. Constants and Variables:

#define MAX_MAC_ADDRESSES 100 static uint8_t
mac_addresses\[MAX_MAC_ADDRESSES\]\[6\]; static int mac_count = 0;

MAX_MAC_ADDRESSES defines the maximum number of MAC addresses the sniffer will track.

mac_addresses stores the unique MAC addresses.

mac_count tracks how many unique MAC addresses have been detected.

3. MAC Address Filtering Functions: Checking if a MAC address has been seen:

bool is_mac_seen(const uint8_t \*mac) { for (int i = 0; i \< mac_count;
i++) { if (memcmp(mac_addresses\[i\], mac, 6) == 0) { return true; //
MAC address found } } return false; }

is_mac_seen checks if a given MAC address is already in the list of previously seen addresses.

Adding a MAC address to the list:

void add_mac_address(const uint8_t *mac) { if (mac_count \<
MAX_MAC_ADDRESSES) { memcpy(mac_addresses\[mac_count\], mac, 6);
mac_count++; } else { // Overwrite the oldest MAC address
memmove(mac_addresses, mac_addresses + 1, (MAX_MAC_ADDRESSES - 1) * 6);
memcpy(mac_addresses\[MAX_MAC_ADDRESSES - 1\], mac, 6); } }

add_mac_address adds a new MAC address to the list, and if the list is full, it overwrites the oldest entry.

4. Wi-Fi Packet Handler:

static void wifi_sniffer_packet_handler(void *buff,
wifi_promiscuous_pkt_type_t type) { const wifi_promiscuous_pkt_t *ppkt =
(wifi_promiscuous_pkt_t *)buff; const uint8_t *payload = ppkt-\>payload;

    if (type == WIFI_PKT_MGMT) {
        // Beacon frame or probe response
        if (payload[0] == 0x80 || payload[0] == 0x50) {
            uint8_t ssid_len = payload[37];
            if (ssid_len > 0 && ssid_len < 33) {
                char ssid[33] = {0};
                memcpy(ssid, &payload[38], ssid_len);
                uint8_t mac[6] = { payload[10], payload[11], payload[12], payload[13], payload[14], payload[15] };

                // Check if this MAC address has been seen before
                if (!is_mac_seen(mac)) {
                    printf("📡 SSID: %s | RSSI: %d | MAC: %02x:%02x:%02x:%02x:%02x:%02x\n",
                        ssid, ppkt->rx_ctrl.rssi,
                        payload[10], payload[11], payload[12],
                        payload[13], payload[14], payload[15]);

                    // Add the MAC address to the list to avoid duplicates
                    add_mac_address(mac);
                }
            }
        }
    } else if (type == WIFI_PKT_DATA) {
        // Optional: Print MAC + RSSI for data frames
        uint8_t mac[6] = { payload[10], payload[11], payload[12], payload[13], payload[14], payload[15] };
        if (!is_mac_seen(mac)) {
            printf("📦 DATA Frame | RSSI: %d | MAC: %02x:%02x:%02x:%02x:%02x:%02x\n",
                ppkt->rx_ctrl.rssi,
                payload[10], payload[11], payload[12],
                payload[13], payload[14], payload[15]);

            // Add the MAC address to the list to avoid duplicates
            add_mac_address(mac);
        }
    }

}

wifi_sniffer_packet_handler processes incoming packets.

It looks for management packets (beacon frames or probe responses) and extracts the SSID and MAC.

It also handles data frames and prints out the RSSI and MAC address if it hasn’t already been seen.

5. Channel Hopping Task:

void channel_hop_task(void \*pvParameters) { uint8_t channel = 1; while
(true) { esp_wifi_set_channel(channel, WIFI_SECOND_CHAN_NONE); //
Suppressed the log output // ESP_LOGI(TAG, "Switched to channel %d",
channel); channel = (channel % 13) + 1; // Loop channels 1-13
vTaskDelay(pdMS_TO_TICKS(500)); } }

The channel_hop_task cycles through Wi-Fi channels 1 to 13 with a 500ms delay, ensuring the sniffer picks up packets from all available channels. The log output showing each channel switch has been suppressed to reduce verbosity.

6. Main Setup and Initialization:

void app_main(void) { ESP_ERROR_CHECK(nvs_flash_init());
ESP_ERROR_CHECK(esp_netif_init());
ESP_ERROR_CHECK(esp_event_loop_create_default());

    wifi_init_config_t cfg = WIFI_INIT_CONFIG_DEFAULT();
    ESP_ERROR_CHECK(esp_wifi_init(&cfg));

    ESP_ERROR_CHECK(esp_wifi_set_storage(WIFI_STORAGE_RAM));
    ESP_ERROR_CHECK(esp_wifi_set_mode(WIFI_MODE_NULL));
    ESP_ERROR_CHECK(esp_wifi_start());

    // Start sniffer
    ESP_ERROR_CHECK(esp_wifi_set_promiscuous(true));
    ESP_ERROR_CHECK(esp_wifi_set_promiscuous_rx_cb(&wifi_sniffer_packet_handler));

    // Start channel hopping task
    xTaskCreate(channel_hop_task, "channel_hop_task", 2048, NULL, 1, NULL);

    ESP_LOGI(TAG, "🚀 Sniffer started. Scanning Wi-Fi activity...");

}

Initializes Wi-Fi and FreeRTOS, enabling promiscuous mode and setting up the packet handler.

Starts the channel hopping task to ensure the sniffer scans all available Wi-Fi channels.

📡 SSID: TL;DR RSSI: -47 MAC: 94:43:c4:4a:35:99
📡 SSID: North Korea’s Wi-Fi RSSI: -91 MAC: 60:83:e9:0b:c9:04

Conclusion:

This project demonstrates how to use the ESP32 in promiscuous mode to detect Wi-Fi networks and track them. It includes features like SSID extraction, MAC address filtering, channel hopping, and real-time reporting, which are essential for building Wi-Fi scanners and network monitors.

You can leverage this implementation for Wi-Fi monitoring, security assessments, or as a foundation for more advanced Wi-Fi-related tools.
